Monoblockhalter SA
Monoblock holders
Utensili monoblocco
HSA-ACS1-S
L
L4
mit ACS
with ACS
con ACS
Seite
Page
Pagina
58–64
R
KL
ET
GTherweaindd1e 1
Filetto 1
1L
GTherweaindd2e 2
Filetto 2
Rechte Ausfhrung abgebildet
Right-hand execution shown
Versione destra in figura
Monoblockhalter mit Innenkhlung ACS1 von der Seite
Monoblock holder with through tool coolant ACS1 access from the side
Utensile monoblocco con adduzione interna ACS1 laterale
Bezeichnung
Designation
Articolo
Gewinde 1 Gewinde 2
EB ET Dmax DR
h
b
L
L4 KL KT Thread 1 Thread 2 PG 37
Filetto 1 Filetto 2
HSA 1616L-SA2402-32-ACS1-S1
2,0 16,0 32 – 16 16 125 20 38 20
M8x1
M8x1
HSA 1616R-SA2402-32-ACS1-S1
2,0 16,0 32 – 16 16 125 20 38 20
M8x1
M8x1
HSA 1616L-SA2403-32-ACS1-S1
3,0 16,0 32 – 16 16 110 20 38 20
M8x1
M8x1
HSA 1616R-SA2403-32-ACS1-S1
3,0 16,0 32 – 16 16 110 20 38 20
M8x1
M8x1
HSA 1616L-SA2403-44-ACS1-S1
3,0 22,0 44 61 16 16 125 20 45 20
M8x1
M8x1
HSA 1616R-SA2403-44-ACS1-S1
3,0 22,0 44 61 16 16 125 20 45 20
M8x1
M8x1
HSA 2020L-SA24025-44-ACS1-S1 2,5 22,0 44 61 20 20 125 20 43 20
M8x1
M8x1
HSA 2020R-SA24025-44-ACS1-S1 2,5 22,0 44 61 20 20 125 20 43 20
M8x1
M8x1
HSA 2020L-SA2403-32-ACS1-S1
3,0 16,0 32 – 20 20 125 20 –
–
M8x1
M8x1
HSA 2020R-SA2403-32-ACS1-S1 3,0 16,0 32 – 20 20 125 20 –
–
M8x1
M8x1
HSA 2020L-SA2403-44-ACS1-S1
3,0 22,0 44 61 20 20 125 20 –
–
M8x1
M8x1
HSA 2020R-SA2403-44-ACS1-S1 3,0 22,0 44 61 20 20 125 20 –
–
M8x1
M8x1
HSA 2020L-SA3503-52-ACS1-S1
3,0 26,0 52 68 20 20 150 20 44 30
M8x1
M8x1
HSA 2020R-SA3503-52-ACS1-S1 3,0 26,0 52 68 20 20 150 20 44 30
M8x1
M8x1
HSA 2020L-SA3503-65-ACS1-S1
3,0 32,5 65 80 20 20 150 20 50 30
M8x1
M8x1
HSA 2020R-SA3503-65-ACS1-S1 3,0 32,5 65 80 20 20 150 20 50 30
M8x1
M8x1
HSA 1616L-SA2402-32-ACS1-S2
2,0 16,0 32 – 16 16 125 20 38 20
HSA 1616R-SA2402-32-ACS1-S2
2,0 16,0 32 – 16 16 125 20 38 20
HSA 1616L-SA2403-32-ACS1-S2
3,0 16,0 32 – 16 16 110 20 38 20
HSA 1616R-SA2403-32-ACS1-S2
3,0 16,0 32 – 16 16 110 20 38 20
HSA 1616L-SA2403-44-ACS1-S2
3,0 22,0 44 61 16 16 125 20 45 20
HSA 1616R-SA2403-44-ACS1-S2
3,0 22,0 44 61 16 16 125 20 45 20
HSA 2020L-SA24025-44-ACS1-S2 2,5 22,0 44 61 20 20 125 20 –
–
HSA 2020R-SA24025-44-ACS1-S2 2,5 22,0 44 61 20 20 125 20 –
–
HSA 2020L-SA2403-32-ACS1-S2
3,0 16,0 32 – 20 20 125 20 –
–
HSA 2020R-SA2403-32-ACS1-S2 3,0 16,0 32 – 20 20 125 20 –
–
HSA 2020L-SA2403-44-ACS1-S2
3,0 22,0 44 61 20 20 125 20 –
–
HSA 2020R-SA2403-44-ACS1-S2 3,0 22,0 44 61 20 20 125 20 –
–
HSA 2020L-SA3503-52-ACS1-S2
3,0 26,0 52 68 20 20 150 20 44 30
HSA 2020R-SA3503-52-ACS1-S2 3,0 26,0 52 68 20 20 150 20 44 30
HSA 2020L-SA3503-65-ACS1-S2
3,0 32,5 65 80 20 20 150 20 50 30
HSA 2020R-SA3503-65-ACS1-S2 3,0 32,5 65 80 20 20 150 20 50 30
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
M8x1
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
Schneideinsatz
Insert
Inserto
SA 24-20…
SA 24-20…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-25…
SA 24-25…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-30…
SA 35-30…
SA 35-30…
SA 35-30…
SA 35-30…
SA 24-20…
SA 24-20…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-25…
SA 24-25…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-30…
SA 35-30…
SA 35-30…
SA 35-30…
SA 35-30…
Alle Angaben in mm / Dimensions in mm / Tutte le dimensioni in mm
