Grade Description
AK 2015 – >> First choice for machining cast materials.
AM 35C – >> First choice for machining steel.
AM 5035 – >> First choice for machining stainless steel.
SHARK-CUT®
Carbide coated
AM5035
(AL350)
HC – P40, HC – M35
PVD-multilayer coating, substrate + TiAlN.
Grade for machining stainless steel, but can also be used for steel materials with low to medium hardness as well as for high
temperature alloys. Optimum cutting edge stability. Excellent results at low to medium cutting speeds.
AK2015
HC – P15, HC – K15 – CVD
CVD-multilayer coating, substrate + TiCN + TiCN + TiCNB + Al2O3
The main application area for this grade is the machining of all cast materials. It is also suitable for machining steel. The new
substrate offers the necessary toughness and heat resistance.
AL10
HC – P10, HC – M15, HC – K10, HC – N15, HC – S10
PVD-multilayer coating, substrate + AlTiN.
Extremly wear resistant grade for machining steel materials, cast iron and non ferrous products. Due to high hardness in coating,
high wear-resistance can be achieved. Specially suitable for high cutting speeds.
AM35C
HC – P35, HC – M30
CVD-multilayer coating, substrate + TiC + TiCN + TiN.
Carbide grade with high toughness for machining steel materiales at medium cutting speeds.
AR26C
HC – P25, HC – K20
CVD-multilayer coating, substrate + TiN + TiCN + Al2O3.
Carbide grade with high wear resistance for machining cast iron and steel materiales.
5
Uncoated carbide grades
AK10
HW – K10, HW – N10, HW – S10
Grade for machining aluminium, aluminium alloys, non-ferrous metals and plastics. Grade can also be used for machining cast
iron and high temperature metals.Insert is peripheryground and the chipbreaker is polished.
AP40
HW – P40, HW – M35
Special carbide grade for steel materiales at cutting speeds below 80 m/min and unstable machining conditions.
174
Размеры указаны в мм
Dimensions in mm
Toutes les dimensions en mm
