Thread turning
для размещения заказа - info@arno-tools.ru
Identification Short description example
M 30
M 20 x 1
M
DIN 6630 - M 64 x 4
DIN 158 - M 30 x 2 keg
G 11/2
G
G 11/2 A
DIN 2999 - Rp 1/2
Rp
DIN 3858 - Rp 1/8
DIN 2999 - R 1/2
R
DIN 3858 - R 1/8 – 1
Tr Tr 40 x 7
S S 48 x 8
Rd
E
W
Pg
UN
UNJ
MJ
NPT
NPTF
ACME
Stub-
ACME
Rd 40 x 1/8
Rd 40 x 5
DIN 40400 - E 27
DIN 477 - W 21,8 x 1/14
DIN 477 - W 28,8 x 1/14 keg
DIN 40430 - Pg 21
1/4 - 20 UNC - 2A
1/4 - 28 UNF - 3A
1/4 - 28 UNJ - 3A
MJ 6 x 1 - 4h6h
MJ 6 x 1 - 4H6H
3/8 - 18 NPT
1/8 - 27 NPTF - 1
13/4 - ACME - 2G
1/2 - 20 Stub-ACME
Description
ISO-metric thread
Coarse pitch
Barrel fittings, external
Metric tapered
external thread
Cylindrical pipe thread,
no sealing thread,
internal thread
External Thread
Cylindrical pipe thread,
sealing thread,
internal thread
Tapered pipe thread,
sealing thread,
external thread
ISO-trapezoidal thread,
general
Buttress thread, general
Round thread, general
Cylindrical round thread
for mining
Electric thread
Cylindrical Whitworth thread
Tapered Whitworth thread
PG thread
American UN thread,
coarse pitch
American UN thread
ne pitch
Aerospace thread
V-thread
Tapered pipe thread
Tapered ne pitch
pipe thread
American
trapezoidal thread
American at
trapezoidal thread
DIN-Standard
DIN 13 T1
DIN 13 T2-11
DIN 6630
DIN 158
DIN ISO 228 T1
DIN ISO 228 T1
DIN 2999 T1
DIN 3858
DIN 2999 T1
DIN 3858
DIN 103 T1-8
DIN 513 T2
DIN 405
DIN 20400
DIN 40400
DIN 477 T1
DIN 40430
DIN ISO 5855-1 und
DIN ISO 5855-2
Available threading insert
• Partial profile 60°
• ISO-metric
(full profile)
• On request
• Partial profile 55°
• Whitworth pipe thread
BSW, BSP (full profile)
• Partial profile 55°
• Whitworth pipe thread
BSW, BSP (full profile)
• Tapered pipe thread
BSPT (full profile)
• Trapezoidal thread DIN 103
(full profile)
• On request
• Round thread DIN 405
(full profile)
• On request
• On request
• Partial profile 55°
• Whitworth pipe thread
BSW, BSP (full profile)
• Tapered Whitworth thread
(full profile)
• PG-thread
DIN 40430 (full profile)
• American UN thread
(full profile)
• Aerospace thread
UNJ (full profile)
• V-thread
MJ (full profile)
• Tapered pipe thread
NPT (full profile)
• Tapered fine pitch pipe thread
NPTF (full profile)
• American trapezoidal thread ACME
(full profile)
• American flat trapezoidal thread
(full profile)
5
REMARK: The above table shows the most common threads. Other threads are available on request.
