ARNO - монолитный осевой инструмент 2015 EN
VHM-Schruppfrser
3 - 5 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide roughing end-mill
3 - 5 flutes, long design
AFG606.1-…
Schaft / Shank
DIN 6535HB
AFG60631-040 N
AFG60631-050 N
AFG60631-060
AFG60631-070 N
AFG60631-080
AFG60641-090
AFG60641-100
AFG60641-120
AFG60641-140
AFG60641-160
AFG60641-180
AFG60641-200
AFG60651-250
Toleranz / Tolerance
(µm)
h10
h6
d
h10
4,0
5,0
6,0
7,0
8,0
9,0
10,0
120
14,0
16,0
18,0
20,0
25,0
NEU/NEW
3-5
Fein / fine
20°
TiAlN
HB
Feinstkorn
Ultra micro
granulation
dA
h6
l1
lz
6
11,0
57 3
6
13,0
57 3
6
16,0
57 3
8
16,0
63 3
8
16,0
63 3
10 19,0 72 4
10 22,0 72 4
12 26,0 83 4
14 26,0 83 4
16 32,0 92 4
18 32,0 92 4
20
38,0
104 4
25
45,0
121 5
Nennwertbereich / Diameter range (m)
>3-6
0
-48
0
-8
> 6 - 10
0
-58
0
-9
> 10 - 18
0
-70
0
-11
> 18 - 30
0
-84
0
-13
Seite
Page
183–192
dA
d
182 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
