VHM-Schaftfrser mit ungleicher Drallsteigung Solid carbide end-mill with unequal pitch
4 Schneiden, kurze Ausfhrung
4 flutes, short design
4
S100
35 - 38°
Feinstkorn
Ultra micro
granulation
HB
Seite
Page
254–261
AFV62342-…
Schaft / Shank
DIN 6535HB
AFV62342-030A N
AFV62342-030B N
AFV62342-030C N
AFV62342-040A N
AFV62342-040B N
AFV62342-040C N
AFV62342-050A N
AFV62342-050B N
AFV62342-050C N
AFV62342-060A N
AFV62342-060B N
AFV62342-060C N
AFV62342-060D N
AFV62342-080A N
AFV62342-080B N
AFV62342-080C N
AFV62342-080D N
AFV62342-100A N
AFV62342-100B N
AFV62342-100C N
AFV62342-100D N
AFV62342-120A N
AFV62342-120B N
AFV62342-120C N
AFV62342-120D N
AFV62342-160A N
AFV62342-160B N
AFV62342-160C N
AFV62342-160D N
AFV62342-200A N
AFV62342-200B N
AFV62342-200C N
AFV62342-200D N
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
3,0
3,0
3,0
4,0
4,0
4,0
5,0
5,0
5,0
6,0
6,0
6,0
6,0
8,0
8,0
8,0
8,0
10,0
10,0
10,0
10,0
12,0
12,0
12,0
12,0
16,0
16,0
16,0
16,0
20,0
20,0
20,0
20,0
0
-0,03
h6
NEU/NEW
dA l1
67
67
68
68
68
6 11
6 10
6 10
6 13
6 10
6 10
6 10
6 13
8 12
8 12
8 19
8 12
10 14
10 14
10 22
10 14
12 16
12 16
12 26
12 16
16 22
16 32
16 22
16 22
20 26
20 38
20 26
20 26
l2 l
12 54
17 57
14 57
15 57
22 63
16 57
17 57
27 67
18 57
15 57
20 62
32 74
21 57
20 63
30 73
27 63
46 90
25 72
35 82
32 72
55 102
30 83
40 93
38 83
64 117
38 92
44 92
55 109
87 141
50 104
54 104
70 124
110 164
dA
d
248 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
