VHM-Schaftfrser mit ungleicher Drallsteigung Solid carbide end-mill with unequal pitch
4 Schneiden, lange Ausfhrung
4 flutes, long design
4 35 - 38°
HB
TiAlN Feinstkorn
Ultra micro
granulation
R
Seite
Page
254–261
AFV61841-…(R…)
Schaft / Shank
DIN 6535HB
AFV61841-030
AFV61841-030R0,3
AFV61841-040
AFV61841-040R0,3
AFV61841-050
AFV61841-050R0,3
AFV61841-060
AFV61841-060R0,5
AFV61841-080
AFV61841-080R0,5
AFV61841-100
AFV61841-100R0,5
AFV61841-100R1,5
AFV61841-100R3,0
AFV61841-120
AFV61841-120R0,7
AFV61841-140
AFV61841-140R0,7
AFV61841-160
AFV61841-160R1,0
AFV61841-160R1,5
AFV61841-160R2,0
AFV61841-160R3,0
AFV61841-180
AFV61841-180R1,0
AFV61841-200
AFV61841-200R1,0
AFV61841-200R2,0
AFV61841-200R3,0
AFV61841-250
AFV61841-250R1,0
AFV61841-250R3,0
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
3,0
3,0
4,0
4,0
5,0
5,0
6,0
6,0
8,0
8,0
10,0
10,0
10,0
10,0
12,0
12,0
14,0
14,0
16,0
16,0
16,0
16,0
16,0
18,0
18,0
20,0
20,0
200
20,0
25,0
25,0
25,0
0
-0,03
h6
dA
6
6
6
6
6
6
6
6
8
8
10
10
10
10
12
12
14
14
16
16
16
16
16
18
18
20
20
20
20
25
25
25
l1 l R
8 57 -
8 57 0,30
11 57
-
11 57 0,30
13 57
-
13 57 0,30
13 57
-
13 57 0,50
19 63
-
19 63 0,50
22 72
-
22 72 0,50
22 72 1,50
22 72 3,00
26 83
-
26 83 0,70
26 83
-
26 83 0,70
32 92
-
32 92 1,00
32 92 1,50
32 92 2,00
32 92 3,00
32 92
-
32 92 1,00
38 104
-
38 104 1,00
38 104 2,00
38 104 3,00
38 104
-
38 104 1,00
38 104 3,00
dA
d
250 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
