ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
2 Schneiden, extra lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
2 flutes, extra long design
AFX50122-…
Schaft / Shank
DIN 6535HA
AFX50122-015A N
AFX50122-015B N
AFX50122-015C N
AFX50122-015D N
AFX50122-015E N
AFX50122-015F N
AFX50122-015G N
AFX50122-015H N
AFX50122-018A N
AFX50122-018B N
AFX50122-018C N
AFX50122-020A N
AFX50122-020B N
AFX50122-020C N
AFX50122-020D N
AFX50122-020E N
AFX50122-020F N
AFX50122-020G N
AFX50122-025A N
AFX50122-025B N
AFX50122-025C N
AFX50122-025D N
AFX50122-030A N
AFX50122-030B N
AFX50122-030C N
AFX50122-030D N
AFX50122-030E N
AFX50122-030F N
AFX50122-030G N
AFX50122-030H N
AFX50122-040A N
AFX50122-040B N
AFX50122-040C N
AFX50122-040D N
AFX50122-040E N
AFX50122-040F N
AFX50122-040G N
AFX50122-050A N
AFX50122-050B N
AFX50122-050C N
AFX50122-050D N
AFX50122-050E N
AFX50122-060A N
AFX50122-060B N
AFX50122-060C N
AFX50122-080A N
AFX50122-100A N
AFX50122-100B N
AFX50122-120A N
AFX50122-120B N
Toleranz / Tolerance
(µm)
Frser / Mill
Schaft / Shank
d
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,5
1,8
1,8
1,8
2,0
2,0
2,0
2,0
2,0
2,0
2,0
2,5
2,5
2,5
2,5
3,0
3,0
3,0
3,0
3,0
3,0
3,0
3,0
4,0
4,0
4,0
4,0
4,0
4,0
4,0
5,0
5,0
5,0
5,0
5,0
6,0
6,0
6,0
8,0
10,0
10,0
12,0
12,0
dA
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
8
10
10
12
12
l1
2,3
2,3
2,3
2,3
2,3
2,3
2,3
2,3
2,7
2,7
2,7
3
3
3
3
3
3
3
4
4
4
4
4,5
4,5
4,5
4,5
4,5
4,5
4,5
4,5
6
6
6
6
6
6
6
8
8
8
8
8
9
9
9
12
15
15
20
20
Nennwertbereich / Diameter range (mm)
<6
0
-0,012
h6
>6
0
-0,015
h6
l2
4,0
6,0
8,0
10,0
12,0
14,0
16,0
20,0
8,0
10,0
12,0
6,0
8,0
10,0
12,0
14,0
16,0
20,0
8,0
12,0
16,0
20,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
26,0
10,0
12,0
16,0
18,0
20,0
26,0
30,0
20,0
30,0
35,0
40,0
50,0
15,0
20,0
30,0
25,0
30,0
45,0
35,0
50,0
l
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
60
60
60
60
65
50
50
60
60
60
65
70
60
70
75
80
90
60
60
70
70
75
100
80
110
274 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
