ARNO - монолитный осевой инструмент 2015 EN
для размещения заказа - info@arno-tools.ru
VHM-Schaftfrser
4 Schneiden, lange Ausfhrung, mit Eckenradius
Solid carbide end-mill
4 flutes, long design, with corner radius
AFX50041-…R…
Schaft / Shank
DIN 6535HA
AFX50041-080AR0,5 N
AFX50041-080AR1,0 N
AFX50041-080BR0,5 N
AFX50041-100AR0,3 N
AFX50041-100AR0,5 N
AFX50041-100AR1,0 N
AFX50041-100AR1,5 N
AFX50041-100BR0,5 N
AFX50041-120AR0,5 N
AFX50041-120AR1,0 N
AFX50041-120AR1,5 N
AFX50041-120AR2,0 N
AFX50041-120BR0,5 N
AFX50041-160AR0,5 N
AFX50041-160AR1,0 N
AFX50041-200AR0,5 N
AFX50041-200AR1,0 N
Toleranz / Tolerance
Frser / Mill
Radius / Radius
Schaft / Shank
d
8,0
8,0
8,0
10,0
10,0
10,0
10,0
10,0
12,0
12,0
12,0
12,0
12,0
16,0
16,0
20,0
20,0
0
-0,03
± 0,02
h6
dA
8
8
8
10
10
10
10
10
12
12
12
12
12
16
16
20
20
l1 l2 l R
12 25,0 70 0,50
12 25,0 70 1,00
20
35,0
100 0,50
15 30,0 75 0,30
15 30,0 75 0,50
15 30,0 75 1,00
15 30,0 75 1,50
25
40,0
100 0,50
18 32,0 80 0,50
18 32,0 80 1,00
18 32,0 80 1,50
18 32,0 80 2,00
30
45,0
110 0,50
20
35,0
100 0,50
20
35,0
100 1,00
25
40,0
100 0,50
25
40,0
100 1,00
282 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
