ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
4 Schneiden, lange Ausfhrung
AFX50141-…
Schaft / Shank
DIN 6535HA
AFX50141-100B N
AFX50141-100C N
AFX50141-100D N
AFX50141-100E N
AFX50141-100F N
AFX50141-120A N
AFX50141-120B N
AFX50141-120C N
AFX50141-120D N
AFX50141-120E N
AFX50141-120F N
AFX50141-120G N
AFX50141-160A N
AFX50141-160B N
AFX50141-160C N
AFX50141-160D N
AFX50141-160E N
AFX50141-180A N
AFX50141-200A N
AFX50141-200B N
AFX50141-250A N
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
10,0
10,0
10,0
10,0
10,0
12,0
12,0
12,0
12,0
12,0
12,0
12,0
14,0
16,0
16,0
16,0
16,0
18,0
20,0
20,0
25,0
0
-0,03
h6
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
4 flutes, long design
dA l1 l
10 30 100
10 35 90
10 40 90
10 45 100
10 50 100
12 35 90
12 40 100
12 45 130
12 50 100
12 55 110
12 60 110
12 60 150
16 50 110
16 50 110
16 60 120
16 70 130
16 70 150
20 50 120
20 60 130
20 90 200
25 90 150
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 287
