ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
2 Schneiden, Mini-Ausfhrung
AF50526-…
Schaft / Shank
DIN 6535HA
AF50526-025D
AF50526-030A
AF50526-030B
AF50526-030C
AF50526-030D
AF50526-030E
AF50526-040A
AF50526-040B
AF50526-040C
AF50526-040D
AF50526-040E
AF50526-040F
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
2,5
3,0
3,0
3,0
3,0
3,0
4,0
4,0
4,0
4,0
4,0
4,0
0
-0,03
h6
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
2 flutes, mini design
dA d3
l1
4,0 2,40 3,7
6,0 2,85 4,5
6,0 2,85 4,5
6,0 2,85 4,5
6,0 2,85 4,5
6,0 2,85 4,5
6,0 3,85 6,0
6,0 3,85 6,0
6,0 3,85 6,0
6,0 3,85 6,0
6,0 3,85 6,0
6,0 3,85 6,0
l2 l
20 50
8 50
12 50
16 60
20 60
25 75
12 50
16 60
20 75
25 75
30 75
35 75
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
