VHM-Schaftfrser
2 Schneiden, kurze Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
2 flutes, short design
2
TiAlN
30°
Feinstkorn
Ultra micro
granulation
HB
Seite
Page
54–61
AF60125-…
Schaft / Shank
DIN 6535HB
AF60125-020
AF60125-030
AF60125-035
AF60125-040
AF60125-045
AF60125-050
AF60125-060
AF60125-070
AF60125-080
AF60125-090
AF60125-100
AF60125-120
AF60125-140
AF60125-160
AF60125-180
AF60125-200
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
2,0
3,0
3,5
4,0
4,5
5,0
6,0
7,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
0
-0,03
h6
dA
6,0
6,0
6,0
6,0
6,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
14,0
16,0
18,0
20,0
l1
3,0
4,0
4,0
5,0
5,0
6,0
7,0
8,0
9,0
10,0
11,0
12,0
14,0
16,0
18,0
20,0
l
50
50
50
54
54
54
54
58
58
66
66
73
75
82
84
92
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 31
