ARNO - монолитный осевой инструмент 2015 EN
PM-HSS-Schaftfrser
4 - 6 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
PM-HSS end-mill
4 - 6 flutes, long design
4-6
TiAlN
30°
PM-HSS
HB
Seite
Page
335–338
FP601.1-…
Schaft / Shank
DIN 6535HB
FP60141-020
FP60141-030
FP60141-040
FP60141-050
FP60141-060
FP60141-070
FP60141-080
FP60141-090
FP60141-100
FP60141-120
FP60141-140
FP60141-160
FP60141-180
FP60141-200
FP60141-220
FP60141-250
FP60161-280
FP60161-300
FP60161-320
d dA l1
lz
2,0
3,0
4,0
5,0
6,0
7,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
25,0
28,0
30,0
32,0
6
6
6
6
6
10
10
10
10
12
12
16
16
20
20
25
25
25
32
10 54 4
12 56 4
19 63 4
24 68 4
24 68 4
30 80 4
38 88 4
38 88 4
45 95 4
53 110 4
53 110 4
63 123 4
63 123 4
75 141 4
75 141 4
90 166 4
90 166 6
90 166 6
106 186 6
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
+ 0,03
0
h6
dA
d
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
