ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
2 Schneiden, extra lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
2 flutes, extra long design
2
TiAlN
30°
Feinstkorn
Ultra micro
granulation
HA
Seite
Page
54–61
AF50122-…
Schaft / Shank
DIN 6535HA
AF50122-030
AF50122-040
AF50122-050
AF50122-060
AF50122-080
AF50122-100
AF50122-120
AF50122-140
AF50122-160
AF50122-180
AF50122-200
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
3,0
4,0
5,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
0
-0,03
h6
dA
3,0
4,0
5,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
l1
20,0
20,0
25,0
30,0
30,0
40,0
45,0
45,0
45,0
45,0
45,0
l
60
60
75
75
75
100
100
100
100
100
100
dA
d
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 35
