ARNO - монолитный осевой инструмент 2015 EN
VHM-Schruppfrser
3 - 5 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide roughing end-mill
3 - 5 flutes, long design
3-5
Grob / coarse
30°
TiAlN
HB
Feinstkorn
Ultra micro
granulation
Seite
Page
54–61
AF614.1-…
Schaft / Shank
DIN 6535HB
AF61431-060
AF61431-080
AF61441-100
AF61441-120
AF61441-140
AF61441-160
AF61441-180
AF61441-200
AF61451-250
Toleranz / Tolerance
(µm)
h0
h6
d
h10
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
25,0
1-3
0
-40
0
-6
dA
h6
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
25,0
l1
16,0
16,0
22,0
26,0
26,0
32,0
32,0
38,0
45,0
lz
57 3
63 3
72 4
83 4
83 4
92 4
92 4
104 4
121 5
Nennwertbereich / Diameter range (mm)
>3-6
0
-48
0
-8
> 6 - 10
0
-58
0
-9
> 10 - 18
0
-70
0
-11
> 18 - 30
0
-84
0
-13
dA
d
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 53
