ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
3 Schneiden, mittellange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
3 flutes, mid-length design
3
TiCN
45°
Feinstkorn
Ultra micro
granulation
HA
AFA51836-…
Schaft / Shank
DIN 6535HA
AFA51836-060 N
AFA51836-080 N
AFA51836-100 N
AFA51836-120 N
AFA51836-140 N
AFA51836-160 N
AFA51836-180 N
AFA51836-200 N
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
0
-0,03
h6
NEU/NEW
dA
6,0
8,0
10,0
12,0
16,0
16,0
20,0
20,0
l1
13,0
19,0
22,0
26,0
28,0
32,0
35,0
38,0
l2 l
20 70
26 80
32 80
36 90
40 110
46 120
50 120
52 120
Seite
Page
98–105
dA
d
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 83
