ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
3 Schneiden, extra lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
3 flutes, extra long design
3
TiCN
45°
Feinstkorn
Ultra micro
granulation
HA
Seite
Page
98–105
AFA50232-…
Schaft / Shank
DIN 6535HA
AFA50232-010A N
AFA50232-010B N
AFA50232-010C N
AFA50232-010D N
AFA50232-010E N
AFA50232-012A N
AFA50232-015A N
AFA50232-015B N
AFA50232-015C N
AFA50232-015D N
AFA50232-020A N
AFA50232-020B N
AFA50232-020C N
AFA50232-020D N
AFA50232-020E N
AFA50232-025A N
AFA50232-025B N
AFA50232-025C N
AFA50232-030A N
AFA50232-030B N
AFA50232-030C N
AFA50232-030D N
AFA50232-030E N
AFA50232-030F N
AFA50232-030G N
AFA50232-035A N
AFA50232-040A N
AFA50232-040B N
AFA50232-040C N
AFA50232-040D N
AFA50232-040E N
AFA50232-040F N
AFA50232-040G N
AFA50232-045A N
AFA50232-050A N
AFA50232-050B N
AFA50232-050C N
AFA50232-050D N
AFA50232-050E N
AFA50232-050F N
AFA50232-050G N
AFA50232-050H N
AFA50232-055A N
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
d
1,0
1,0
1,0
1,0
1,0
1,2
1,5
1,5
1,5
1,5
2,0
2,0
2,0
2,0
2,0
2,5
2,5
2,5
3,0
3,0
3,0
3,0
3,0
3,0
3,0
3,5
4,0
4,0
4,0
4,0
4,0
4,0
4,0
4,5
5,0
5,0
5,0
5,0
5,0
5,0
5,0
5,0
5,5
NEU/NEW
dA l1 l
6,0 3,0 50
6,0 2,0 40
6,0 2,5 40
6,0 4,0 60
6,0 6,0 60
6,0 4,0 50
6,0 5,0 50
6,0 3,0 40
6,0 8,0 60
6,0
10,0
60
6,0 6,0 50
6,0 3,0 40
6,0 8,0 60
6,0
10,0
60
6,0
12,0
60
6,0
10,0
55
6,0 8,0 40
6,0
12,0
60
6,0
11,0
55
6,0 4,0 45
6,0 8,0 45
6,0
15,0
65
6,0
20,0
70
6,0
25,0
75
6,0
30,0
80
6,0
12,0
55
6,0
13,0
55
6,0 5,0 45
6,0
11,0
45
6,0
16,0
65
6,0
20,0
70
6,0
26,0
75
6,0
30,0
80
6,0
15,0
55
6,0 17,0 55
6,0 6,0 45
6,0
22,0
60
6,0
25,0
70
6,0
30,0
75
6,0
35,0
80
6,0
40,0
85
6,0
45,0
90
6,0 17,0 55
dA
d
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 89
