ARNO - монолитный осевой инструмент 2015 EN
VHM-Radiusfrser
3 Schneiden, kurze Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide ball-nose end-mill
3 flutes, short design
3
TiCN
40°
Feinstkorn
Ultra micro
granulation
HA
Seite
Page
98–105
NEU/NEW
AFA51831-…
Schaft / Shank
DIN 6535HA
AFA51831-020
AFA51831-025
AFA51831-030
AFA51831-035
AFA51831-040
AFA51831-050
AFA51831-060
AFA51831-080
AFA51831-100
AFA51831-120
AFA51831-160
AFA51831-200 N
Toleranz / Tolerance
Frser / Mill
Radius / Radius
Schaft / Shank
d dA d3 l1 l2 l R
2,0
2,5
3,0
3,5
4,0
5,0
6,0
8,0
10,0
12,0
16,0
20,0
6,0
6,0
6,0
6,0
6,0
6,0
6,0
8,0
10,0
12,0
16,0
20,0
1,90
2,40
2,80
3,20
3,70
4,60
5,60
7,40
9,40
11,40
15,40
18,00
3,0
4,0
4,5
5,0
6,0
7,5
9,0
12,0
15,0
18,0
24,0
30,0
5
6
6,5
7
8
10
12
25
30
36
40
50
60 1,00
60 1,25
60 1,50
65 1,75
65 2,00
65 2,50
75 3,00
75 4,00
80 5,00
90 6,00
100 8,00
110 10,00
0
-0,03
±0,01
h6
dA
d3
d
92 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
