ARNO - инструмент для автоматов продольного точения EN

для размещения заказа - info@arno-tools.ru

Monoblockhalter SA

Monoblock holders

Utensili monoblocco

HSA

KL

L

ohne IK

without ic

senza ic

Seite

Page

Pagina

58–64

R

1 ET

L

Rechte Ausfhrung abgebildet

Right-hand execution shown

Versione destra in figura

Fr Langdrehautomaten / For sliding head auto lathes / Per fantina mobile

Bezeichnung

Designation

Articolo

HSA 0808L-SA16015-12

HSA 0808R-SA16015-12

HSA 0808L-SA16015-16

HSA 0808R-SA16015-16

HSA 0808L-SA24015-12

HSA 0808R-SA24015-12

HSA 0808L-SA24015-16

HSA 0808R-SA24015-16

HSA 1010L-SA16015-20

HSA 1010R-SA16015-20/span>

HSA 1010L-SA1602-20

HSA 1010R-SA1602-20

HSA 1010L-SA24015-20

HSA 1010R-SA24015-20

HSA 1010L-SA2402-20

HSA 1010R-SA2402-20

HSA 1212L-SA16015-20

HSA 1212R-SA16015-20

HSA 1212L-SA1602-20

HSA 1212R-SA1602-20

HSA 1212L-SA1603-26

HSA 1212R-SA1603-26

HSA 1212L-SA24015-20

HSA 1212R-SA24015-20

HSA 1212L-SA24015-26

HSA 1212R-SA24015-26

HSA 1212L-SA24015-32

HSA 1212R-SA24015-32

HSA 1212L-SA2402-20

HSA 1212R-SA2402-20

HSA 1212L-SA2402-26

HSA 1212R-SA2402-26

HSA 1212L-SA2402-32

HSA 1212R-SA2402-32

HSA 1212L-SA24025-26

HSA 1212R-SA24025-26

HSA 1212L-SA24025-32

HSA 1212R-SA24025-32

EB ET Dmax DR

h

b

L KL KT PG 37

1,5 6,0 12

–

8

8 110 16 10

1,5 6,0 12

–

8

8 110 16 10

1,5 8,0 16

–

8

8

110 18

10

1,5 8,0 16

–

8

8

110 18

10

1,5 6,0 12

–

8

8 110 16 10

1,5 6,0

12

–

8

8 110 16 10

1,5 8,0 16

–

8

8 110 18 10

1,5 8,0 16

–

8

8 110 18 10

1,5 10,0

20

–

10 10 110 20 12

1,5 10,0

20

–

10 10 110 20 12

2,0 10,0 20 – 10 10 110 20 12

2,0 10,0 20 – 10 10 110 20 12

1,5 10,0 20 – 10 10 110 20 12

1,5 10,0 20 – 10 10 110 20 12

2,0 10,0 20 – 10 10 110 20 12

2,0 10,0 20 – 10 10 110 20 12

1,5 13,0 26 – 12 12 110 –

–

1,5 13,0 26 – 12 12 110 –

–

2,0 10,0 20 – 12 12 110 –

–

2,0 10,0

20

–

12 12 110 –

–

3,0 13,0 26 – 12 12 110 – –

3,0 13,0 26 – 12 12 110 –

–

1,5 10,0 20 – 12 12 110 – –

1,5 10,0 20 – 12 12 110 – –

1,5 13,0 26 – 12 12 110 – –

1,5 13,0 26 – 12 12 110 –

–

1,5 16,0 32 – 12 12 110 26 16

1,5 16,0 32 – 12 12 110 26 16

2,0 10,0 20 – 12 12 110 –

–

2,0 10,0 20 – 12 12 110 –

–

2,0 13,0 26 – 12 12 110 –

–

2,0 13,0 26 – 12 12 110 –

–

2,0 16,0 32 – 12 12 110 26 16

2,0 16,0 32 – 12 12 110 26 16

2,5 13,0 26 – 12 12 110 – –

2,5 13,0 26 – 12 12 110 – –

2,5 16,0

32

–

12 12 110 26 16

2,5 16,0 32 – 12 12 110 26 16

Schneideinsatz

Insert

Inserto/div>
