Monoblockhalter SA

Monoblock holders

Utensili monoblocco

Fr Langdrehautomaten / For sliding head auto lathes / Per fantina mobile

Bezeichnung

Designation

Articolo

HSA 1616L-SA1602-20

HSA 1616R-SA1602-20

HSA 1616L-SA1602-26

HSA 1616R-SA1602-26

HSA 1616L-SA1603-26

HSA 1616R-SA1603-26

HSA 1616L-SA24015-32

HSA 1616R-SA24015-32

HSA 1616L-SA2402-26

HSA 1616R-SA2402-26

HSA 1616L-SA2402-32

HSA 1616R-SA2402-32

HSA 1616L-SA24025-32

HSA 1616R-SA24025-32

HSA 1616L-SA2403-20

HSA 1616R-SA2403-20

HSA 1616L-SA2403-26

HSA 1616R-SA2403-26

HSA 1616L-SA2403-32

HSA 1616R-SA2403-32

HSA 2020L-SA1603-26

HSA 2020R-SA1603-26

HSA 2020L-SA2402-20

HSA 2020R-SA2402-20

HSA 2020L-SA2402-32

HSA 2020R-SA2402-32

HSA 2020L-SA2403-32

HSA 2020R-SA2403-32

EB ET Dmax DR

L KL KT PG 37

2,0 10,0 20 – 16 16 110 –

–

2,0 10,0 20 – 16 16 110 – –

2,0 13,0 26 – 16 16 110 – –

3,0 13,0 26 – 16 16 110 –

–

3,0 13,0 26 – 16 16 110 –

–

1,5 16,0 32 – 16 16 110 –

–

1,5 16,0 32 – 16 16 110 –

–

2,0 13,0 26 – 16 16 110 –

–

2,0 13,0 26 – 16 16 110 –

–

2,0 16,0 32 – 16 16 110 –

–

2,0 16,0 32 – 16 16 110 – –

2,5 16,0 32 – 16 16 110 – –

3,0 10,0 20 – 16 16 110 –

–

3,0 10,0 20 – 16 16 110 –

–

3,0 13,0 26 – 16 16 110 –

–

3,0 13,0 26 – 16 16 110 –

–

3,0 16,0 32 – 16 16 110 –

–

3,0 16,0 32 – 16 16 110 –

–

3,0 13,0 26 – 20 20 110 – –

3,0 13,0 26 – 20 20 110 –

–

2,0 10,0 20 – 20 20 110 – –

2,0 16,0 32

–

110 25,5

2,0 16,0

–

110 25,5

3,0 16,0 32 – 20 20 110 –

–

3,0 16,0 32 – 20 20 110 –

–

Dmax = Maximaler Durchmesser bei Vollmaterial

Dmax = Maximum diameter in solid

Dmax = Diametro massimo lavorazione dal pieno

Schneideinsatz

Insert

Inserto

SA 16-20…

SA 16-30…

SA 24-15…

SA 24-20…

SA 24-25…

SA 24-30…

SA 16-30…

SA 24-20…

SA 24-30…

Ersatzteile / Spare parts / Ricambi

Halter

Holder

Stelo

HSA 0808...

HSA 1010... - HSA 2020...

Schraube

Screw

Vite

AS 0022-12

AS 0022

Schlssel

Key

Chiave

KS 8000

Alle Angaben in mm / Dimensions in mm / Tutte le dimensioni in mm
