Monoblockhalter SA
Monoblock holders
Utensili monoblocco
HSA
L
ohne IK
without ic
senza ic
Seite
Page
Pagina
58–64
R
KL
1ET L
Monoblockhalter / Monoblock holder / Utensile monoblocco
Bezeichnung
Designation
Articolo
HSA 1616L-SA24015-44
HSA 1616R-SA24015-44
HSA 1616L-SA2402-44
HSA 1616R-SA2402-44
HSA 1616L-SA2403-44
HSA 1616R-SA2403-44
HSA 2020L-SA24015-44
HSA 2020R-SA24015-44
HSA 2020L-SA2402-44
HSA 2020R-SA2402-44
HSA 2020L-SA24025-44
HSA 2020R-SA24025-44
HSA 2020L-SA2403-44
HSA 2020R-SA2403-44
HSA 2020L-SA3502-52
HSA 2020R-SA3502-52
HSA 2020L-SA3502-65
HSA 2020R-SA3502-65
HSA 2020L-SA3503-52
HSA 2020R-SA3503-52
HSA 2020L-SA3503-65
HSA 2020R-SA3503-65
EB ET Dmax DR
h
b
L KL KT
1,5 22,0 44 61 16 16 125 40 20
1,5 22,0 44 61 16 16 125 40 20
2,0 22,0 44 61 16 16 125 40 20
2,0 22,0 44 61 16 16 125 40 20
3,0 22,0 44 61 16 16 125 40 20
3,0 22,0 44 61 16 16 125 40 20
1,5 22,0 44 61 20 20 125 –
–
1,5 22,0 44 61 20 20 125 –
–
2,0 22,0 44 61 20 20 125 –
–
2,0 22,0 44 61 20 20 125 –
–
2,5 22,0 44 61 20 20 125 –
–
2,5 22,0 44 61 20 20 125 –
–
3,0 22,0 44 61 20 20 125 –
–
3,0 22,0 44 61 20 20 125 –
–
2,0 26,0 52 68 20 20 150 44 30
2,0 26,0 52 68 20 20 150 44 30
2,0 32,5 65 80 20 20 150 50 30
2,0 32,5 65 80 20 20 150 50 30
3,0 26,0 52 68 20 20 150 44 30
3,0 26,0 52 68 20 20 150 44 30
3,0 32,5 65 80 20 20 150 50 30
3,0 32,5 65 80 20 20 150 50 30
Rechte Ausfhrung abgebildet
Right-hand execution shown
Versione destra in figura
PG 37
Schneideinsatz
Insert
Inserto
SA 24-15…
SA 24-15…
SA 24-20…
SA 24-20…
SA 24-30…
SA 24-30…
SA 24-15…
SA 24-15…
SA 24-20…
SA 24-20…
SA 24-25…
SA 24-25…
SA 24-30…
SA 24-30…
SA 35-20…
SA 35-20…
SA 35-20…
SA 35-20…
SA 35-30…
SA 35-30…
SA 35-30…
SA 35-30…
Ersatzteile / Spare parts / Ricambi
Halter
Holder
Stelo
HSA 1616… - HSA 2020… Dmax 44
HSA 2020… Dmin 52/65
Schraube
Screw
Vite
DIN912 M5x16-12.9
DIN912 M6x20-12.9
Schlssel
Key
Chiave
KP 1321
KP 5421
Alle Angaben in mm / Dimensions in mm / Tutte le dimensioni in mm
ARNO®-Werkzeuge | Langdrehen | Auto lathes | Fantina mobile 41
