HSA-ACS1-H
L
mit ACS
with ACS
con ACS
Seite
Page
Pagina
58–64
R
KL
1 ET
GTherweaindd1e 1
Filetto 1
L
Rechte Ausfhrung abgebildet
Right-hand execution shown
Versione destra in figura
Monoblockhalter mit Innenkhlung ACS1 von hinten
Monoblock holder with through tool coolant ACS1 access from the back
Utensile monoblocco con adduzione interna ACS1 posteriore
Bezeichnung
Designation
Articolo
Gewinde 1 Gewinde 2
EB ET Dmax DR
h
b
L
L4 KL KT Thread 1 Thread 2 PG 37
Filetto 1 Filetto 2
HSA 1616L-SA2402-32-ACS1-H1
2,0 16,0 32 – 16 16 125
38 20
M8x1
–
HSA 1616R-SA2402-32-ACS1-H1 2,0 16,0 32 – 16 16 125
38 20
M8x1
–
HSA 1616L-SA2403-32-ACS1-H1
3,0 16,0 32,0 – 16 16 125 – 38 20
M8x1
–
HSA 1616R-SA2403-32-ACS1-H1
3,0 16,0 32,0 – 16 16 125 – 38 20
M8x1
–
HSA 1616L-SA2403-44-ACS1-H1
3,0 22,0 44,0 61 16 16 125 – 45 20
M8x1
–
HSA 1616R-SA2403-44-ACS1-H1
3,0 22,0 44,0 61 16 16 125 – 45 20
M8x1
–
HSA 2020L-SA24025-44-ACS1-H1 2,5 22,0 44 61 20 20 125
––
M8x1
–
HSA 2020R-SA24025-44-ACS1-H1 2,5 22,0 44 61 20 20 125
––
M8x1
–
HSA 2020L-SA2403-32-ACS1-H1 3,0 16,0 32,0 – 20 20 125 – – –
M8x1
–
HSA 2020R-SA2403-32-ACS1-H1 3,0 16,0 32,0 – 20 20 125 – – –
M8x1
–
HSA 2020L-SA2403-44-ACS1-H1 3,0 22,0 44,0 61 20 20 125 – – –
M8x1
–
HSA 2020R-SA2403-44-ACS1-H1 3,0 22,0 44,0 61 20 20 125 – – –
M8x1
–
HSA 2020L-SA3503-52-ACS1-H1 3,0 26,0 52,0 68 20 20 150 – 44 30
M8x1
–
HSA 2020R-SA3503-52-ACS1-H1 3,0 26,0 52,0 68 20 20 150 – 44 30
M8x1
–
HSA 2020L-SA3503-65-ACS1-H1 3,0 32,5 65,0 80 20 20 150 – 50 30
M8x1
–
HSA 2020R-SA3503-65-ACS1-H1 3,0 32,5 65,0 80 20 20 150 – 50 30
M8x1
–
HSA 1616L-SA2402-32-ACS1-H2
2,0 16,0 32 – 16 16 125
HSA 1616R-SA2402-32-ACS1-H2 2,0 16,0 32 – 16 16 125
HSA 1616L-SA2403-32-ACS1-H2
3,0 16,0 32 – 16 16 125 –
HSA 1616R-SA2403-32-ACS1-H2 3,0 16,0 32 – 16 16 125 –
HSA 1616L-SA2403-44-ACS1-H2
3,0 22,0 44 61 16 16 125 –
HSA 1616R-SA2403-44-ACS1-H2 3,0 22,0 44 61 16 16 125 –
HSA 2020L-SA24025-44-ACS1-H2 2,5 22,0 44 61 20 20 125
HSA 2020R-SA24025-44-ACS1-H2 2,5 22,0 44 61 20 20 125
HSA 2020L-SA2403-32-ACS1-H2 3,0 16,0 32 – 20 20 125 –
HSA 2020R-SA2403-32-ACS1-H2 3,0 16,0 32 – 20 20 125 –
HSA 2020L-SA2403-44-ACS1-H2 3,0 22,0 44 61 20 20 125 –
HSA 2020R-SA2403-44-ACS1-H2 3,0 22,0 44 61 20 20 125 –
HSA 2020L-SA3503-52-ACS1-H2 3,0 26,0 52 68 20 20 150 –
HSA 2020R-SA3503-52-ACS1-H2 3,0 26,0 52 68 20 20 150 –
HSA 2020L-SA3503-65-ACS1-H2 3,0 32,5 65 80 20 20 150 –
HSA 2020R-SA3503-65-ACS1-H2 3,0 32,5 65 80 20 20 150 –
38 20
38 20
38 20
38 20
45 20
45 20
––
––
––
––
––
––
44 30
44 30
50 30
50 30
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
G 1/8"
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Schneideinsatz
Insert
Inserto
SA 24-20…
SA 24-20…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-25…
SA 24-25…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-30…
SA 35-30…
SA 35-30…
SA 35-30…
SA 35-30…
SA 24-20…
SA 24-20…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-25…
SA 24-25…
SA 24-30…
SA 24-30…
SA 24-30…
SA 24-30…
SA 35-30…
SA 35-30…
SA 35-30…
SA 35-30…
