ARNO - каталог сверление 2013 EN
Vollhartmetall NC-Anbohrer
Solid carbide NC spot drills
Punta da centro in MD integrale
NC-Anbohrer 120°
NC spot drill 120° / Punta da centro 120°
Bezeichnung
Designation
Articolo
SPA0020-120
SPA0030-120
SPA0040-120
SPA0050-120
SPA0060-120
SPA0080-120
SPA0100-120
SPA0120-120
SPA0140-120
SPA0160-120
SPA0180-120
SPA0200-120
d1 d2
h6 h6
l1
l2
A
2,0 2 40 8 120°
3,0 3 40 10 120°
4,0 4 40 12 120°
5,0 5 50 15 120°
6,0 6 50 20 120°
8,0 8 63 22 120°
10,0
10
74
23 120°
12,0
12
83
25 120°
14,0
14
83
26 120°
16,0
16
92
28 120°
18,0
18
92
30 120°
20,0
20
104
30 120°
5
для размещения заказа - info@arno-tools.ru
2 Schneiden, 120°
Vollhartmetall NC-Anbohrer
2 flutes, 120°
2 taglienti, 120°
Solid carbide NC spot drills
Punta da centro in MD integrale
Seite
Page
Pagina
249 – 256
h6 2 2,0 - 20,0 mm
TiAlN
Feinstkorn-Micro-Grain
Ultra micro granulation
Ultra micro grana
h6 120°
d2
NC-Anbohrer 135°
NC spot drill 135° / Punta da centro 135°
Bezeichnung
Designation
Articolo
SPA0120-135
SPA0160-135
SPA0200-135
d1 d2
h6 h6
l1
l2
A
12,0
12
83
25 135°
16,0
16
92
28 135°
20,0
20
104
30 135°
d1
A
2 Schneiden, 135°
2 flutes, 135°
2 taglienti, 135°
Seite
Page
Pagina
249 – 256
h6 2 12,0 -20,0 mm
TiAlN
Feinstkorn-Micro-Grain
Ultra micro granulation
Ultra micro grana
h6 135°
d2
d1
A
5
242 ARNO®-Werkzeuge | Bohren | Drilling | Foratura
Alle Angaben in mm / Dimensions in mm / Tutte le dimensioni in mm
info@arno-tools.ru
www.arno-tools.ru
Alle Angaben in mm / Dimensions in mm / Tutte le dimensioni in mm
ARNO®-Werkzeuge | Bohren | Drilling | Foratura 243
