Spare parts
Ricambi
Spare parts
Ricambi
1
Halter und Zubehr / Holder accessories / Accessori corpi
Bezeichnung
Designation
Articolo
2KDA
3KDA
4KDA
5KDA
6KDA
Passend zu Haltern der Serien
Used on the holder series
Utilizzati sui corpi serie
A-C-E-G
I-K-M
O-Q
S
U-W
Schnellkupplung
Fast action coupling
Attacco rapido
SK-2KDA
SK-3KDA
SK-4KDA
SK-5KDA
SK-6KDA
Khlmitteladapter
Rotary coolant adapters
Anello refrigerante
R-2KDA
R-3KDA
R-4KDA
R-5KDA
R-6KDA
Sttzstange
Solid steady bar
Barra anti rotazione
SS-2KDA
SS-3KDA
SS-4KDA
SS-5KDA
SS-6KDA
Schnellkupplung
Fast action coupling
Attacco rapido
Bezeichnung
Designation
Articolo
SK-2KDA
SK-3KDA
SK-4KDA
SK-5KDA
SK-6KDA
Norm. Rohr-Gewinde E
Norm pipe thread
Filetto GAS
1/8
1/8
1/4
1/4
1/2
Schlauch- S
Hose S
Tubo S
9 mm
9 mm
9 mm
12 mm
12 mm
Schrauben und Schraubendreher / Screws and Screwdrivers / Chiavi e Viti
Bezeichnung
Designation
Articolo
A
C
E
G
I
K
M
O
Q
S
U
W
fr -Bereich
Drill Range used with
Campo serie
9,5–11,0
11,5–12,8
13,0–17,5
15,5–17,5
17,8–24,0
22,0–24,0
24,5–35,0
30,0–35,0
36,0–47,0
48,0–65,0
66,0–89,0
90,0–114,0
Torx Schraubendreher
Screwdriver Torx
Chiave Torx
T5107
T5107
T5108
T5108
T5109
T5109
T5115
T5115
T5120
T5120
T5125
T5125
Anzugsmoment
Torque
Momento seraggio
0,6 Nm
0,6 Nm
1,3 Nm
1,3 Nm
2,2 Nm
2,2 Nm
5,1 Nm
5,1 Nm
6,2 Nm
6,2 Nm
8,1 Nm
8,1 Nm
Hinweis: Drehmoment-Schraubendreher siehe Seite 281.
Remark: For torque screwdrivers see page 281.
Nota: Chiavi dianamomentriche a pagina 281.
Schrauben
Screws
Vite
AS 0011
AS 0011
AS 0012
AS 0018
AS 0013
AS 0019
AS 0014
AS 0014
AS 0015
AS 0015
AS 0016
AS 0016
1
Khlmitteladapter
Rotary coolant adapter
Anello refrigerante
Bezeichnung
Designation
Articolo
R-2KDA
R-3KDA
R-4KDA
R-5KDA
R-6KDA
A
19,05
25,40
31,75
44,45
57,15
B
44,45
53,97
63,50
76,20
95,27
Sttzstange
Solid steady bar
Barra anti rotazione
Bezeichnung
Designation
Articolo
SS-2KDA
SS-3KDA
SS-4KDA
SS-5KDA
SS-6KDA
Gewindegre
Thread size
Filetto
M8
M8
M10
M10
M12
94 ARNO®-Werkzeuge | Bohren | Drilling | Foratura
C
22,23
28,57
34,92
34,92
44,45
D
M8
M8
M10
M10
M12
E
1/8
1/8
1/4
1/4
1/2
L1 [mm]
250
250
250
250
250
