ARNO - каталог сверление 2013 EN
Kurzlochbohrer
Short hole drill
Sistema di foratura
для размещения заказа - info@arno-tools.ru
ARNO® AKB
Kurzlochbohrer
Short hole drill
Sistema di foratura
ARNO® AKB
DIN ISO 9766
mit IK
with ic
con ic
Seite
Page
Pagina
161 – 166
x3D
3
3D Trgerwerkzeug / Drill holder / Corpo punta
Bezeichnung
Designation
Articolo
AKB3-1400R20-04
AKB3-1450R20-04
AKB3-1500R20-04
AKB3-1550R20-05
AKB3-1600R20-05
AKB3-1650R20-05
AKB3-1700R20-05
AKB3-1750R25-05
AKB3-1800R25-05
AKB3-1850R25-06
AKB3-1900R25-06
AKB3-1950R25-06
AKB3-2000R25-06
AKB3-2050R25-06
AKB3-2100R25-06
AKB3-2150R25-06
AKB3-2200R25-06
AKB3-2250R25-06
AKB3-2300R25-07
AKB3-2350R25-07
AKB3-2400R25-07
AKB3-2450R25-07
AKB3-2500R25-07
AKB3-2550R32-07
AKB3-2600R32-07
AKB3-2650R32-07
AKB3-2700R32-07
AKB3-2750R32-07
AKB3-2800R32-07
AKB3-2850R32-07
AKB3-2900R32-09
AKB3-2950R32-09
AKB3-3000R32-09
AKB3-3000R40-09
AKB3-3100R32-09
AKB3-3100R40-09
AKB3-3200R32-09
AKB3-3200R40-09
AKB3-3300R32-09
D
14,0
14,5
15,0
15,5
16,0
16,5
17,0
17,5
18,0
18,5
19,0
19,5
20,0
20,5
21,0
21,5
22,0
22,5
23,0
23,5
24,0
24,5
25,0
25,5
26,0
26,5
27,0
27,5
28,0
28,5
29,0
29,5
30,0
30,0
31,0
31,0
32,0
32,0
33,0
I
60,0
61,5
63,0
64,5
66,0
67,5
69,0
70,5
72,0
73,5
75,0
76,5
78,0
79,5
81,0
82,5
84,0
85,5
90,0
91,5
93,0
94,5
96,0
99,5
101,0
102,5
104,0
105,5
107,0
108,5
112,0
113,5
118,0
118,0
121,0
121,0
124,0
124,0
127,0
I2
42,0
43,5
45,0
46,5
48,0
49,5
51,0
52,5
54,0
55,5
57,0
58,5
60,0
61,5
63,0
64,5
66,0
67,5
69,0
70,5
72,0
73,5
75,0
76,5
78,0
79,5
81,0
82,5
84,0
85,5
87,0
88,5
90,0
90,0
93,0
93,0
96,0
96,0
99,0
I3
44
44
44
44
44
44
44
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
60
60
60
60
60
60
60
60
60
70
70
70
70
70
70
70
Wendeschneidplatte
dA
Insert
Inserto
20 XDMT 04…
20 XDMT 04…
20 XDMT 04…
20 XDMT 05…
20 XDMT 05…
20 XDMT 05…
20 XDMT 05…
25 XDMT 05…
25 XDMT 05…
25 XDMT 06…
25 XDMT 06…
25 XDMT 06…
25 XDMT 06…
25 XDMT 06…
25 XDMT 06…
25 XDMT 06…
25 XDMT 06…
25 XDMT 06…
25 XDMT 07…
25 XDMT 07…
25 XDMT 07…
25 XDMT 07…
25 XDMT 07…
32 XDMT 07…
32 XDMT 07…
32 XDMT 07…
32 XDMT 07…
32 XDMT 07…
32 XDMT 07…
32 XDMT 07…
32 XDMT 09…
32 XDMT 09…
32 XDMT 09…
40 XDMT 09…
32 XDMT 09…
40 XDMT 09…
32 XDMT 09…
40 XDMT 09…
32 XDMT 09…
HINWEIS: Trgerwerkzeuge werden mit 2 Klemmschrauben und Schlssel geliefert. Bitte beachten Sie unsere Schnittdatenempfehlungen auf Seite 161.
INFORMATION: H olders will be supplied with 2 clamping screws and key. Please note cutting recommendations on page 162.
NOTA: L’utensile fornito completo di 2 viti e 1 chiave. Per parametri di taglio e informazioni tecniche vedi pagina 163.
3D Trgerwerkzeug / Drill holder / Corpo punta
Bezeichnung
Designation
Articolo
AKB3-3300R40-09
AKB3-3400R32-09
AKB3-3400R40-09
AKB3-3500R32-09
AKB3-3500R40-09
AKB3-3600R32-09
AKB3-3600R40-09
AKB3-3700R32-12
AKB3-3700R40-12
AKB3-3800R32-12
AKB3-3800R40-12
AKB3-3900R32-12
AKB3-3900R40-12
AKB3-4000R32-12
AKB3-4000R40-12
AKB3-4100R32-12
AKB3-4100R40-12
AKB3-4200R32-12
AKB3-4200R40-12
AKB3-4300R32-12
AKB3-4300R40-12
AKB3-4400R32-12
AKB3-4400R40-12
AKB3-4500R32-12
AKB3-4500R40-12
D
33,0
34,0
34,0
35,0
35,0
36,0
36,0
37,0
37,0
38,0
38,0
39,0
39,0
40,0
40,0
41,0
41,0
42,0
42,0
43,0
43,0
44,0
44,0
45,0
45,0
I
127,0
130,0
130,0
133,0
133,0
136,0
136,0
146,0
146,0
149,0
149,0
152,0
152,0
155,0
155,0
158,0
158,0
161,0
161,0
164,0
164,0
167,0
167,0
170,0
170,0
I2
99,0
102,0
102,0
105,0
105,0
108,0
108,0
111,0
111,0
114,0
114,0
117,0
117,0
120,0
120,0
123,0
123,0
126,0
126,0
129,0
129,0
132,0
132,0
135,0
135,0
I3
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
70
Wendeschneidplatte
dA
Insert
Inserto
40 XDMT 09…
32 XDMT 09…
40 XDMT 09…
32 XDMT 09…
40 XDMT 09…
32 XDMT 09…
40 XDMT 09…
32 XDMT 12…
40 XDMT 12…
32 XDMT 12…
40 XDMT 12…
32 XDMT 12…
40 XDMT 12…
32 XDMT 12…
40 XDMT 12…
32 XDMT 12…
40 XDMT 12…
32 XDMT 12…
40 XDMT 12…
32 XDMT 12…
40 XDMT 12…
32 XDMT 12…
40 XDMT 12…
32 XDMT 12…
40 XDMT 12…
HINWEIS: Trgerwerkzeuge werden mit 2 Klemmschrauben und Schlssel geliefert.
Bitte beachten Sie unsere Schnittdatenempfehlungen auf Seite 161.
INFORMATION: H olders will be supplied with 2 clamping screws and key.
Please note c utting recommendations on page 162.
NOTA: L’utensile fornito completo di 2 viti e 1 chiave.
Per parametri di taglio e informazioni tecniche vedi pagina 163.
3
154 ARNO®-Werkzeuge | Bohren | Drilling | Foratura
Alle Angaben in mm / Dimensions in mm / Tutte le dimensioni in mm
info@arno-tools.ru
www.arno-tools.ru
Alle Angaben in mm / Dimensions in mm / Tutte le dimensioni in mm
ARNO®-Werkzeuge | Bohren | Drilling | Foratura 155
