ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
2 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
2 flutes, long design
2 30° HA
DIAMANT
DLC
Fr NE-Metalle
For non-ferrous
materials
D100
Fr Graphit
For Graphite
Feinstkorn
Ultra micro
granulation
Seite
Page
128–130
AFD50121-…
Schaft / Shank
DIN 6535HA
AFD50121-005
AFD50121-006
AFD50121-007
AFD50121-008
AFD50121-009
AFD50121-010
AFD50121-015
AFD50121-020
AFD50121-025
AFD50121-030
AFD50121-035
AFD50121-040
AFD50121-050
AFD50121-060
AFD50121-070
AFD50121-080
AFD50121-090
AFD50121-100
AFD50121-110
AFD50121-120
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
0,5
0,6
0,7
0,8
0,9
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
6,0
7,0
8,0
9,0
10,0
11,0
12,0
dA
3
3
3
3
3
4
4
4
4
6
6
6
6
6
6
8
8
10
10
12
0
-0,03
h6
d3
0,45
0,55
0,65
0,75
0,85
0,95
1,45
1,90
2,40
2,80
3,20
3,70
4,60
5,60
-
7,40
-
9,40
-
11,40
l1
1,0
2,0
2,0
2,0
2,0
3,0
4,0
6,0
8,0
8,0
10,0
20,0
25,0
30,0
35,0
40,0
45,0
50,0
50,0
55,0
l2
2,0
3,0
4,0
5,0
6,0
8,0
10,0
16,0
20,0
30,0
35,0
40,0
50,0
60,0
-
80,0
-
80,0
-
80,0
l
40
40
40
40
40
75
75
100
100
100
100
100
125
140
140
150
150
150
150
150
dA
d3
d
110 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
D100 = speziell fr die Graphitbearbeitung
DLC = fr die Bearbeitung von NE-Metallen
D100 = especially for graphite machining
DLC = for machining of non-ferrous materials
Alle Angaben in mm / Dimensions in mm
