ARNO - монолитный осевой инструмент 2015 EN
VHM-Radiusfrser
2 Schneiden, berlange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide ball-nose end-mill
2 flutes, extra long design
2 30° HA
DIAMANT
DLC
Fr NE-Metalle
For non-ferrous
materials
D100
Fr Graphit
For Graphite
Feinstkorn
Ultra micro
granulation
Seite
Page
143–145
AFD51823-…
Schaft / Shank
DIN 6535HA
AFD51823-020
AFD51823-030
AFD51823-040
AFD51823-050
AFD51823-060
AFD51823-070
AFD51823-080
AFD51823-090
AFD51823-100
AFD51823-120
Toleranz / Tolerance
Frser / Mill
Radius / Radius
Schaft / Shank
d
2,0
3,0
4,0
5,0
6,0
7,0
8,0
9,0
10,0
12,0
dA d3 l1
l2
l
R
4
1,95
10,0
20,0
100
1,00
4
2,90
15,0
25,0
100
1,50
4 3,90 20,0 30,0 100 2,00
6 4,90 30,0 50,0 120 2,50
6 5,50 30,0 50,0 150 3,00
6 - 30,0 - 150 3,50
8 7,50 40,0 60,0 150 4,00
8 - 40,0 - 150 4,50
10 9,50 50,0 70,0 180 5,00
12
11,50
55,0
75,0
200
6,00
0
-0,03
± 0,01
h6
dA
d3
d
116 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
D100 = speziell fr die Graphitbearbeitung
DLC = fr die Bearbeitung von NE-Metallen
D100 = especially for graphite machining
DLC = for machining of non-ferrous materials
Alle Angaben in mm / Dimensions in mm
