ARNO - монолитный осевой инструмент 2015 EN
VHM-Radiusfrser
3 Schneiden, kurze Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide ball-nose end-mill
3 flutes, short design
3 30° HA
DIAMANT
DLC
Fr NE-Metalle
For non-ferrous
materials
D100
Fr Graphit
For Graphite
Feinstkorn
Ultra micro
granulation
Seite
Page
155–157
AFD51830-…
Schaft / Shank
DIN 6535HA
AFD51830-020
AFD51830-025
AFD51830-030
AFD51830-035
AFD51830-040
AFD51830-050
AFD51830-060
AFD51830-080
AFD51830-100
AFD51830-120
Toleranz / Tolerance
Frser / Mill
Radius / Radius
Schaft / Shank
d dA d3 l1 l2 l R
2,0
6
1,90
3,0
5,0
60 1,00
2,5
6
2,40
4,0
6,0
60 1,25
3,0
6
2,80
4,5
6,5
60 1,50
3,5
6
3,20
5,0
7,0
65 1,75
4,0
6
3,70
6,0
8,0
65 2,00
5,0 6 4,60 7,5 10,0 65 2,50
6,0 6 5,60 9,0 12,0 75 3,00
8,0
8
7,40
12,0
25,0
75
4,00
10,0
10
9,40
15,0
30,0
80
5,00
12,0
12
11,40
18,0
36,0
90
6,00
0
-0,03
± 0,01
h6
dA
d3
d
120 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
D100 = speziell fr die Graphitbearbeitung
DLC = fr die Bearbeitung von NE-Metallen
D100 = especially for graphite machining
DLC = for machining of non-ferrous materials
Alle Angaben in mm / Dimensions in mm
