ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
4 Schneiden, mit Eckenradius
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
4 flutes, with corner radius
4 30° HA
DIAMANT DLC D100R
Fr NE-Metalle
For non-ferrous
materials
Fr Graphit
For Graphite
Seite
Page
158–160
Feinstkorn
Ultra micro
granulation
AFD50740-…R…
Schaft / Shank
DIN 6535HA
AFD50740-060AR0,5
AFD50740-080AR0,5
AFD50740-080BR1,0
AFD50740-100AR0,5
AFD50740-100BR0,5
AFD50740-100CR1,0
AFD50740-100DR0,5
AFD50740-120AR0,5
AFD50740-120BR0,5
AFD50740-120CR1,0
AFD50740-120DR1,0
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
6,0
8,0
8,0
10,0
10,0
10,0
10,0
12,0
12,0
12,0
12,0
dA d3 l1
l2
l
R
6
5,90
10,0
40,0
80
0,50
8
7,80
10,0
40,0
80
0,50
8
7,80
10,0
60,0
100
1,00
10 - 25,0 - 75 0,50
10
9,80
12,0
40,0
80
0,50
10
9,80
12,0
40,0
80
1,00
10
9,80
12,0
80,0
125
0,50
12 - 25,0 - 80 0,50
12
11,80
15,0
40,0
80
0,50
12
11,80
15,0
40,0
80
1,00
12
11,80
15,0
80,0
125
1,00
0
-0,03
h6
dA
d3
d
D100 = speziell fr die Graphitbearbeitung
DLC = fr die Bearbeitung von NE-Metallen
D100 = especially for graphite machining
DLC = for machining of non-ferrous materials
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 121
