VHM-Schaftfrser
6-8 Schneiden, extra lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
6-8 flutes, extra long design
6-8
TiAlN
45°
Feinstkorn
Ultra micro
granulation
HB
AFG602.0-…
Schaft / Shank
DIN 6535HB
AFG60240-040 N
AFG60260-060 N
AFG60260-070 N
AFG60260-080 N
AFG60260-100 N
AFG60260-120 N
AFG60260-140 N
AFG60260-160 N
AFG60280-180 N
AFG60280-200 N
AFG60280-250 N
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
4,0
6,0
7,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
25,0
0
-0,03
h6
NEU/NEW
dA l1
6 11,0
6 13,0
8 16,0
8 19,0
10 22,0
12 26,0
14 26,0
16 32,0
18 32,0
20 38,0
25 44,0
lz
57 4
57 6
63 6
63 6
72 6
83 6
83 6
92 6
92 8
104 8
104 8
Seite
Page
183–192
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 177
