ARNO - монолитный осевой инструмент 2015 EN
для размещения заказа - info@arno-tools.ru
VHM-Torus-Schaftfrser / Hochvorschubfrser Solid carbide high-feed end-mill
4 Schneiden, lange Ausfhrung, mit Eckenradius
4 flutes, long design, with corner radius
4 90° HA
TiA70 Feinstkorn
Ultra micro
granulation
R
Seite
Page
229–243
AFH50741-…R…
Schaft / Shank
DIN 6535HA
AFH50741-020 R0.5
AFH50741-030 R0.5
AFH50741-040 R0.5
AFH50741-050 R0.5
AFH50741-060 R0.5
AFH50741-060 R1.0
AFH50741-080 R1.0
AFH50741-080 R2.0
AFH50741-100 R1.0
AFH50741-100 R2.0
AFH50741-120 R2.0
AFH50741-120 R3.0
AFH50741-160 R3.0
Toleranz / Tolerance
Frser / Mill
Radius / Radius
Schaft / Shank
d
2,0
3,0
4,0
5,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
12,0
16,0
0
-0,02
± 0,005
h6
dA d3 l1
l2
l
R
6
1,80
1,00
6,0
70 0,50
6
2,80
1,20
8,0
70 0,50
6
3,80
1,50
10,0
70
0,50
6
4,60
2,00
10,0
70
0,50
6
5,40
2,50
12,0
90
0,50
6
5,40
2,50
12,0
90
1,00
8 7,20 3,50 16,0 100 1,00
8 7,20 3,50 16,0 100 2,00
10 9,00 4,00 20,0 100 1,00
10 9,00 4,00 20,0 100 2,00
12
11,00
5,00
25,0
110
2,00
12
11,00
5,00
25,0
110
3,00
16
15,00
6,50
30,0
130
3,00
dA
d3
d
228 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
