ARNO - монолитный осевой инструмент 2015 EN
VHM-Radiusfrser
2 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide ball-nose end-mill
2 flutes, long design
AFX50321-…
Schaft / Shank
DIN 6535HA
AFX50321-080A N
AFX50321-080B N
AFX50321-080C N
AFX50321-080D N
AFX50321-080E N
AFX50321-080F N
AFX50321-090 N
AFX50321-100A N
AFX50321-100B N
AFX50321-100C N
AFX50321-100D N
AFX50321-100E N
AFX50321-100F N
AFX50321-110 N
AFX50321-120A N
AFX50321-120B N
AFX50321-120C N
AFX50321-120D N
AFX50321-120E N
AFX50321-120F N
AFX50321-130A N
AFX50321-140A N
AFX50321-160A N
AFX50321-160B N
AFX50321-200A N
AFX50321-200B N
Toleranz / Tolerance
(µm)
Frser / Mill
Radius / Radius
Schaft / Shank
d
8,0
8,0
8,0
8,0
8,0
8,0
9,0
10,0
10,0
10,0
10,0
10,0
10,0
11,0
12,0
12,0
12,0
12,0
12,0
12,0
13,0
14,0
16,0
16,0
20,0
20,0
dA
8
8
8
8
8
8
10
10
10
10
10
10
10
12
12
12
12
12
12
12
12
14
16
16
20
20
l1
12
12
12
12
14
14
18
15
15
18
18
18
18
20
18
18
22
22
22
22
24
26
24
30
30
38
Nennwertbereich / Diameter range (mm)
<6
0
-0,012
0
±0,005
h6
>6
0
-0,015
0
±0,010
h6
l
50
60
80
90
100
150
100
60
90
100
130
150
180
100
80
100
110
130
150
200
100
100
100
150
100
150
R
4,00
4,00
4,00
4,00
4,00
4,00
4,50
5,00
5,00
5,00
5,00
5,00
5,00
5,50
6,00
6,00
6,00
6,00
6,00
6,00
6,50
7,00
8,00
8,00
10,00
10,00
276 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
