ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
4 Schneiden, kurze Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
4 flutes, short design
4 <3mm 30° 3mm 26-30°
S100
Feinstkorn
Ultra micro
granulation
Seite
Page
290–305
HA
AFX50140-…
Schaft / Shank
DIN 6535HA
AFX50140-010 N
AFX50140-015 N
AFX50140-020 N
AFX50140-025 N
AFX50140-030 N
AFX50140-035 N
AFX50140-040 N
AFX50140-045 N
AFX50140-050 N
AFX50140-055 N
AFX50140-060 N
AFX50140-065 N
AFX50140-070 N
AFX50140-075 N
AFX50140-080 N
AFX50140-085 N
AFX50140-090 N
AFX50140-095 N
AFX50140-100 N
AFX50140-105 N
AFX50140-110 N
AFX50140-115 N
AFX50140-120 N
AFX50140-130 N
AFX50140-140 N
AFX50140-160 N
AFX50140-180 N
AFX50140-200 N
AFX50140-250 N
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
1,0
1,5
2,0
2,5
3,0
3,5
4,0
4,5
5,0
5,5
6,0
6,5
7,0
7,5
8,0
8,5
9,0
9,5
10,0
10,5
11,0
11,5
12,0
13,0
14,0
16,0
18,0
20,0
25,0
0
-0,03
h6
NEU/NEW
dA
6
6
6
6
6
6
6
6
6
6
6
8
8
8
8
10
10
10
10
12
12
12
12
12
14
16
18
20
25
l1 l
2,5 50
4 50
6 50
7 50
8 50
10 50
10 50
14 50
15 60
15 60
15 60
18 60
20 60
20 60
20 70
22 70
22 70
24 70
25 75
26 75
30 75
30 80
30 80
35 100
35 100
40 100
45 100
45 100
50 120
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 279
