ARNO - монолитный осевой инструмент 2015 EN
VHM-Radiusfrser
2 Schneiden, lange Ausfhrung (Schlitzfrsen)
для размещения заказа - info@arno-tools.ru
Solid carbide ball-nose end-mill
2 flutes, long design (Slotting)
AFX52021-…
Schaft / Shank
DIN 6535HA
AFX52021-020A N
AFX52021-020B N
AFX52021-030A N
AFX52021-030B N
AFX52021-030C N
AFX52021-030D N
AFX52021-030E N
AFX52021-030F N
AFX52021-030G N
AFX52021-030H N
AFX52021-030I N
AFX52021-030J N
AFX52021-040A N
AFX52021-040B N
AFX52021-040C N
AFX52021-040D N
AFX52021-040E N
AFX52021-040F N
AFX52021-040G N
AFX52021-040H N
AFX52021-040I N
AFX52021-040J N
AFX52021-050A N
AFX52021-060A N
AFX52021-060B N
AFX52021-080A N
AFX52021-080B N
AFX52021-100A N
AFX52021-100B N
AFX52021-100C N
AFX52021-120A N
AFX52021-120B N
Toleranz / Tolerance
(µm)
Frser / Mill
Radius / Radius
Schaft / Shank
d
2,0
2,0
3,0
3,0
3,0
3,0
3,0
3,0
3,0
3,0
3,0
3,0
4,0
4,0
4,0
4,0
4,0
4,0
4,0
4,0
4,0
4,0
5,0
6,0
6,0
8,0
8,0
10,0
10,0
10,0
12,0
12,0
dA l1
l2
6 2 8,0
6 2 10,0
6 3 8,0
6 3 10,0
6 3 12,0
6 3 14,0
6 3 16,0
6 3 18,0
6 3 20,0
6 3 26,0
6 3 30,0
6 3 35,0
6 4 10,0
6 4 12,0
6 4 14,0
6 4 16,0
6 4 18,0
6 4 20,0
6 4 26,0
6 4 30,0
6 4 35,0
6 4 40,0
6 6 30,0
6 8 20,0
6 8 30,0
8 10 25,0
8 14 35,0
10 12 30,0
10 18 30,0
10 18 40,0
12 14 32,0
12 22 32,0
Nennwertbereich / Diameter range (mm)
<6
0
-0,012
0
±0,005
h6
>6
0
-0,015
0
±0,010
h6
lR
50 1,00
50 1,00
50 1,50
50 1,50
50 1,50
60 1,50
60 1,50
60 1,50
60 1,50
65 1,50
70 1,50
70 1,50
50 2,00
50 2,00
60 2,00
60 2,00
60 2,00
60 2,00
65 2,00
70 2,00
70 2,00
80 2,00
70 2,50
60 3,00
60 3,00
70 4,00
100 4,00
75 5,00
100 5,00
100 5,00
80 6,00
110 6,00
278 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
