ARNO - монолитный осевой инструмент 2015 EN
PM-HSS-Radiusfrser
2 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
PM-HSS ball-nose end-mill
2 flutes, long design
2
TiAlN
30°
PM-HSS
HB
Seite
Page
335–338
FP60321-…
Schaft / Shank
DIN 6535HB
FP60321-030
FP60321-040
FP60321-050
FP60321-060
FP60321-070
FP60321-080
FP60321-090
FP60321-100
FP60321-120
FP60321-140
FP60321-160
FP60321-180
FP60321-200
FP60321-220
FP60321-250
Toleranz / Tolerance
Frser / Mill
Radius / Radius
Schaft / Shank
d
3,0
4,0
5,0
6,0
7,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
25,0
0
-0,03
±0,02
h6
dA
6
6
6
6
10
10
10
10
12
12
16
16
20
20
25
l1 l R
8 56 1,50
11 63 2,00
13 68 2,50
13 68 3,00
16 80 3,50
19 88 4,00
19 88 4,50
22 95 5,00
26 110 6,00
26 110 7,00
32 123 8,00
32 123 9,00
38 141 10,00
38 141 11,00
45 166 12,50
dA
d
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 315
