PM-HSS-Schaftfrser
3 Schneiden, extra kurze Ausfhrung
для размещения заказа - info@arno-tools.ru
PM-HSS end-mill
3 flutes, extra short design
3
TiAlN
30°
PM-HSS
HB
Seite
Page
335–338
FP60135-…
Schaft / Shank
DIN 6535HB
FP60135-020
FP60135-030
FP60135-040
FP60135-050
FP60135-060
FP60135-070
FP60135-080
FP60135-090
FP60135-100
FP60135-120
FP60135-140
FP60135-160
FP60135-180
FP60135-200
FP60135-220
FP60135-250
Toleranz / Tolerance
(µm)
e8
h6
d
e8
2,0
3,0
4,0
5,0
6,0
7,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
25,0
1 -3
-14
-28
0
-6
dA
h6
l1 l
6 4 48
6 5 49
6 7 51
6 8 52
6 8 52
10 10 60
10 11 61
10 11 61
10 13 63
12 16 73
12 16 73
16 19 79
16 19 79
20 22 88
20 22 88
25 26 102
Nennwertbereich / Diameter range (mm)
>3 -6
-20
-38
0
-8
>6 -10
-25
-47
0
-9
>10 -18
-32
-59
0
-11
>18 -30
-40
-73
0
-13
dA
d
316 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
