ARNO - монолитный осевой инструмент 2015 EN
PM-HSS-Schruppfrser
3 - 6 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
PM-HSS roughing end-mill
3 - 6 flutes, long design
3-6
< 20 mm
30°
Fein / fine
HB
TiAlN
> 20 mm
PM-HSS
Seite
Page
335–338
FP618.1-…
Schaft / Shank
DIN 6535HB
FP61831-060
FP61831-070
FP61831-080
FP61831-090
FP61841-100
FP61841-120
FP61841-140
FP61841-160
FP61841-180
FP61841-200
FP61851-220
FP61851-250/div>
FP61861-280
FP61861-300
FP61861-320
Toleranz / Tolerance
(µm)
js12
h6
d
js12
6,0
7,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
25,0
28,0
30,0
32,0
dA
h6
l1
lz
6 24 68 3
10 30 80 3
10 38 88 3
10 38 88 3
10 45 95 4
12 53 110 4
12 53 110 4
16 63 123 4
16 63 123 4
20 75 141 4
20 75 141 5
25 90 166 5
25 90 166 6
25 90 166 6
32 106 186 6
Nennwertbereich / Diameter range (mm)
>6 -10
±75
0
-9
>10 -18
±90
0
-11
>18 -30
±105
0
-13
30 -50
±125
0
-16
dA
d
322 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
