ARNO - монолитный осевой инструмент 2015 EN
PM-HSS-Schruppfrser
4 - 6 Schneiden, extra kurze Ausfhrung
для размещения заказа - info@arno-tools.ru
PM-HSS roughing end-mill
4 - 6 flutes, extra short design
4-6
< 20 mm
45°
Fein / fine
HB
TiAlN
> 20 mm
PM-HSS
Seite
Page
335–338
FP619.5-…
Schaft / Shank
DIN 6535HB
FP61945-060
FP61945-080
FP61945-100
FP61945-120
FP61955-140
FP61955-160
FP61965-180
FP61965-200
FP61965-250
Toleranz / Tolerance
(µm)
js12
h6
d
js12
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
25,0
dA
h6
l1
l2
lz
68
- 52 4
10 11 - 61 4
10
13 23,0 63
4
12 16 28,0 73 4
12 16 - 73 5
16
19 31,0 79
5
16 19 - 79 6
20 22 38,0 88 6
25
26
46,0
102
6
Nennwertbereich / Diameter range (mm)
>6 -10
±75
0
-9
>10 -18
±90
0
-11
>18 -30
±105
0
-13
dA
d
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 323
