ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
3 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
3 flutes, long design
3
TiAlN
45°
Feinstkorn
Ultra micro
granulation
HB
Seite
Page
54–61
AF60231-…
Schaft / Shank
DIN 6535HB
AF60231-030
AF60231-035
AF60231-040
AF60231-045
AF60231-050
AF60231-060
AF60231-070
AF60231-080
AF60231-090
AF60231-100
AF60231-120
AF60231-140
AF60231-160
AF60231-180
AF6021-200
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
3,0
3,5
4,0
4,5
5,0
6,0
7,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
0
-0,03
h6
dA
6,0
6,0
6,0
6,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
14,0
16,0
18,0
20,0
l1
7,0
7,0
8,0
8,0
10,0
10,0
13,0
16,0
16,0
span id="f2" style="font-size:6px;vertical-align:baseline;color:#231f1f;">19,0
22,0
22,0
26,0
26,0
32,0
l
57
57
57
57
57
57
63
63
72
72
83
83
92
92
104
dA
d
SET-AF60231 TiAlN
SET-Inhalt
SET, contains
[Stck / Pcs.]
2x -->
2x -->
2x -->
2x -->
Schaft
Shank
AF60231-060
AF60231-080
AF60231-100
AF60231-120
d
6,0
8,0
10,0
12,0
Bestellbezeichnung / Ordering description: SET-AF60231 TiAIN
dA
6
8
10
12
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
l1 l
10 57
16 63
19 72
22 83
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 43
