ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
3 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
3 flutes, long design
3
TiAlN
30°
Feinstkorn
Ultra micro
granulation
HB
Seite
Page
54–61
AF60131-…
Schaft / Shank
DIN 6535HB
AF60131-030
AF60131-040
AF60131-050
AF60131-060
AF60131-080
AF60131-090
AF60131-100
AF60131-120
AF60131-140
AF60131-160
AF60131-180
AF60131-200
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
3,0
4,0
5,0
6,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
0
-0,03
h6
dA
6,0
6,0
6,0
6,0
8,0
10,0
10,0
12,0
14,0
16,0
18,0
20,0
l1
7,0
8,0
10,0
10,0
16,0
16,0
19,0
22,0
22,0
26,0
26,0
32,0
l
57
57
57
57
63
72
72
83
83
92
92
104
42 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
