ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
4 Schneiden, kurze Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
4 flutes, short design
4
TiAlN
30°
Feinstkorn
Ultra micro
granulation
HB
Seite
Page
54–61
AF60140-… X
Schaft / Shank
DIN 6535HB
AF60140-020X
AF60140-025X
AF60140-030X
AF60140-035X
AF60140-040X
AF60140-045X
AF60140-050X
AF60140-060X
AF60140-070X
AF60140-080X
AF60140-090X
AF60140-100X
AF60140-120X
AF60140-140X
AF60140-160X
AF60140-180X
AF60140-200X
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
2,0
2,5
3,0
3,5
4,0
4,5
5,0
6,0
7,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
0
-0,03
h6
dA
6,0
6,0
6,0
6,0
6,0
6,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
14,0
16,0
18,0
20,0
l1
4,0
4,0
5,0
6,0
8,0
8,0
9,0
10,0
11,0
12,0
13,0
14,0
16,0
18,0
22,0
24,0
26,0
l
50
50
50
50
54
54
54
54
58
58
66
66
73
75
82
84
92
46 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
