VHM-Schaftfrser
4 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
4 flutes, long design
4 30° HA
TiAlN
Feinstkorn
Ultra micro
granulation
Seite
Page
54–61
HB
AF50141-… / AF60141-…
Schaft / Shank
DIN 6535HA / HB
AF50141-020*
AF60141-030
AF60141-035
AF60141-040
AF60141-045
AF60141-050
AF60141-060
AF60141-070
AF60141-080
AF60141-090
AF60141-100
AF60141-120
AF60141-140
AF60141-160
AF60141-180
AF60141-200
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
2,0
3,0
3,5
4,0
4,5
5,0
6,0
7,0
8,0
9,0
10,0
12,0
14,0
16,0
18,0
20,0
0
-0,03
h6
dA
3,0
6,0
6,0
6,0
6,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
14,0
16,0
18,0
20,0
l1
7,0
8,0
10,0
11,0
11,0
13,0
13,0
16,0
19,0
19,0
22,0
26,0
26,0
32,0
32,0
38,0
l
38
57
57
57
57
57
57
63
63
72
72
83
83
92
92
104
* Zylinderschaft nach DIN 6535HA ohne Mitnahmeflche
* Cylindrical shank to DIN 6535HA, no flat
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 47
