ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
3 Schneiden, lange Ausfhrung, unbeschichtet
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
3 flutes, long design, uncoated
3
Unbeschichtet
Uncoated
AK1010
30°
Feinstkorn
Ultra micro
granulation
HA
Seite
Page
98–105
AFA52330-…
Schaft / Shank
DIN 6535HA
AFA52330-035
AFA52330-040
AFA52330-045
AFA52330-050
AFA52330-055
AFA52330-060
AFA52330-065
AFA52330-070
AFA52330-075
AFA52330-080
AFA52330-085
AFA52330-090
AFA52330-095
AFA52330-100
AFA52330-110
AFA52330-120
AFA52330-130
AFA52330-140
AFA52330-150
AFA52330-160
AFA52330-180
AFA52330-200
Toleranz / Tolerance
(µm)
h10
h6
d
h10
3,5
4,0
4,5
5,0
5,5
6,0
6,5
7,0
7,5
8,0
8,5
9,0
9,5
10,0
11,0
12,0
13,0
14,0
15,0
16,0
18,0
20,0
1-3
0
-40
0
-6
dA
h6
3,5
4,0
4,5
5,0
5,5
6,0
6,5
7,0
7,5
8,0
8,5
9,0
9,5
10,0
11,0
12,0
13,0
14,0
15,0
16,0
18,0
20,0
l1
7,0
8,0
8,0
10,0
10,0
10,0
13,0
13,0
16,0
16,0
16,0
16,0
19,0
19,0
22,0
22,0
22,0
22,0
26,0
26,0
26,0
32,0
l
50
50
50
50
57
57
60
60
63
63
67
67
72
72
83
83
83
83
92
92
92
104
Nennwertbereich / Diameter range (mm)
>3-6
0
-48
0
-8
> 6 - 10
0
-58
0
-9
> 10 - 18
0
-70
0
-11
> 18 - 30
0
-84
0
-13
dA
d
Achtung: Vc -30% bei unbeschichteten Werkzeugen
Attention: Vc -30% with uncoated tools
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 85
