ARNO - монолитный осевой инструмент 2015 EN
VHM-Schaftfrser
3 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide end-mill
3 flutes, long design
3
TiCN
45°
Feinstkorn
Ultra micro
granulation
HA
Seite
Page
98–105
AFA51531…
Schaft / Shank
DIN 6535HA
AFA51531-030
AFA51531-030A
AFA51531-040
AFA51531-040A
AFA51531-050
AFA51531-050A
AFA51531-060
AFA51531-060A
AFA51531-070
AFA51531-080
AFA51531-080A
AFA51531-090
AFA51531-100
AFA51531-100A
AFA51531-120
AFA51531-120A
AFA51531-140
AFA51531-160
AFA51531-160A
AFA51531-180
AFA51531-200
AFA51531-200A
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
3,0
3,0
4,0
4,0
5,0
5,0
6,0
6,0
7,0
8,0
8,0
9,0
10,0
10,0
12,0
12,0
14,0
16,0
16,0
18,0
20,0
20,0
0
-0,03
h6
dA
6,0
6,0
6,0
6,0
6,0
6,0
6,0
6,0
8,0
8,0
8,0
10,0
10,0
10,0
12,0
12,0
14,0
16,0
16,0
16,0
20,0
20,0
l1
11,0
14,0
13,0
16,0
17,0
22,0
17,0
22,0
22,0
22,0
28,0
27,0
27,0
32,0
32,0
38,0
37,0
42,0
52,0
48,0
48,0
55,0
l
50
65
50
65
55
70
55
70
65
65
80
70
70
90
80
95
85
100
110
110
110
110
dA
d
86 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
