VHM-Schaftfrser
3 Schneiden, lange Ausfhrung, mit Eckenradius
Solid carbide end-mill
3 flutes, long design, with corner radius
AFA50231-…R…
Schaft / Shank
DIN 6535HA
AFA50231-030R0,5 N
AFA50231-030R1,0 N
AFA50231-040R0,5 N
AFA50231-040R1,0 N
AFA50231-050R0,5 N
AFA50231-050R1,0 N
AFA50231-060R0,5 N
AFA50231-060R1,0 N
AFA50231-080R0,5 N
AFA50231-080R1,0 N
AFA50231-100R0,5 N
AFA50231-100R1,0 N
AFA50231-100R2,0 N
AFA50231-120R0,5 N
AFA50231-120R1,0 N
AFA50231-120R2,0 N
AFA50231-160R0,5 N
AFA50231-160R1,0 N
AFA50231-160R2,0 N
AFA50231-200R0,5 N
AFA50231-200R1,0 N
AFA50231-200R2,0 N
Toleranz / Tolerance
Frser / Mill
Schaft / Shank
d
3,0
3,0
4,0
4,0
5,0
5,0
6,0
6,0
8,0
8,0
10,0
10,0
10,0
12,0
12,0
12,0
16,0
16,0
16,0
20,0
20,0
20,0
0
-0,015
h6
NEU/NEW
dA
6,0
6,0
6,0
6,0
6,0
6,0
6,0
6,0
8,0
8,0
10,0
10,0
10,0
12,0
12,0
12,0
16,0
16,0
16,0
20,0
20,0
20,0
l1
12,0
12,0
15,0
15,0
20,0
20,0
20,0
20,0
22,0
22,0
25,0
25,0
25,0
25,0
25,0
25,0
35,0
35,0
35,0
40,0
40,0
40,0
3 45° HA
TiCN
Feinstkorn
Ultra micro
R
granulation
lR
57 0,50
57 1,00
57 0,50
57 1,00
57 0,50
57 1,00
65 0,50
span id="f2" style="font-size:6px;vertical-align:baseline;color:#231f1f;">65 1,00
65 0,50
65 1,00
70 0,50
70 1,00
70 2,00
75 0,50
75 1,00
75 2,00
90 0,50
90 1,00
90 2,00
100 0,50
100 1,00
100 2,00
Seite
Page
98–105
dA
d
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 87
