ARNO - монолитный осевой инструмент 2015 EN
VHM-Schruppfrser
3 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide roughing end-mill
3 flutes, long design
3
TiCN
42°
Feinstkorn
Ultra micro
granulation
HA
Seite
Page
98–105
AFA52131-…
Schaft / Shank
DIN 6535HA
AFA52131-040A
AFA52131-060A
AFA52131-060B
AFA52131-060C
AFA52131-070A
AFA52131-080A
AFA52131-080B
AFA52131-080C
AFA52131-100A
AFA52131-100B
AFA52131-100C
AFA52131-120A
AFA52131-120B
AFA52131-120C
AFA52131-160A
AFA52131-160B
AFA52131-160C
AFA52131-200A
AFA52131-200B
AFA52131-200C
Toleranz / Tolerance
(µm)
js12
h6
d
js12
4,0
6,0
6,0
6,0
7,0
8,0
8,0
8,0
10,0
10,0
10,0
12,0
12,0
12,0
16,0
16,0
16,0
20,0
20,0
20,0
dA
h6
6,0
6,0
6,0
6,0
8,0
8,0
8,0
8,0
10,0
10,0
10,0
12,0
12,0
12,0
16,0
16,0
16,0
20,0
20,0
20,0
1-3
±50
0
-6
l1
6,0
10,0
18,0
30,0
20,0
12,0
20,0
30,0
14,0
26,0
40,0
16,0
30,0
50,0
20,0
40,0
56,0
24,0
46,0
60,0
l2
14
20
-
-
-
26
-
-
30
-
-
36
-
-
42
-
-
52
-
-
l Typ/Type
60 M
60 O
70 O
65 O
80 M
65 O
100 O
85 M
70 O
100 O
100 M
80 O
120 O
110 M
100 O
120 O
110 M
100 O
120 O
Nennwertbereich / Diameter range (mm)
>3-6
±60
0
-8
> 6 - 10
±75
0
-9
> 10 - 18
±90
0
-11
> 18 - 30
±105
0
-13
dA
d
Typ/Type O Typ/Type M
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools 95
