ARNO - монолитный осевой инструмент 2015 EN
VHM-Schruppfrser
3 Schneiden, lange Ausfhrung
для размещения заказа - info@arno-tools.ru
Solid carbide roughing end-mill
3 flutes, long design
3
TiCN
45°
Feinstkorn
Ultra micro
granulation
HA
AFA51931-…
Schaft / Shank
DIN 6535HA
AFA51931-040 N
AFA51931-050 N
AFA51931-060 N
AFA51931-060A N
AFA51931-080 N
AFA51931-080A N
AFA51931-100 N
AFA51931-100A N
AFA51931-120 N
AFA51931-120A N
AFA51931-140 N
AFA51931-160 N
AFA51931-160A N
span id="f1" style="font-size:6px;vertical-align:baseline;color:#231f1f;">AFA51931-180 N
AFA51931-200 N
AFA51931-200A N
Toleranz / Tolerance
(µm)
h10
h6
d
h10
4,0
5,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
12,0
14,0
16,0
16,0
18,0
20,0
20,0
NEU/NEW
dA
h6
6,0
6,0
6,0
6,0
8,0
8,0
10,0
10,0
12,0
12,0
16,0
16,0
16,0
20,0
20,0
20,0
l1
10,0
15,0
15,0
25,0
20,0
30,0
25,0
40,0
30,0
50,0
35,0
42,0
52,0
45,0
48,0
55,0
l
55
55
60
80
65
90
70
100
80
110
90
100
150
100
100
160
Nennwertbereich / Diameter range (mm)
>3-6
0
-48
0
-8
> 6 - 10
0
-58
0
-9
> 10 - 18
0
-70
0
-11
> 18 - 30
0
-84
0
-13
Seite
Page
98–105
dA
d
96 ARNO®-Werkzeuge | VHM-/PM-HSS Werkzeuge | Solid carbide-/PM-HSS Tools
info@arno-tools.ru
www.arno-tools.ru
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
