VHM-Schruppfrser
3 Schneiden, lange Ausfhrung, abgesetzter Schaft
Solid carbide roughing end-mill
3 flutes, long design, with neck
3
TiCN
45°
Feinstkorn
Ultra micro
granulation
HA
AFA52331-…
Schaft / Shank
DIN 6535HA
AFA52331-040 N
AFA52331-050 N
AFA52331-060 N
AFA52331-080 N
AFA52331-100 N
AFA52331-120 N
AFA52331-160 N
AFA52331-200 N
Toleranz / Tolerance
(µm)
h10
h6
d
h10
4,0
5,0
6,0
8,0
10,0
12,0
16,0
20,0
NEU/NEW
dA
h6
6,0
6,0
6,0
8,0
10,0
12,0
16,0
20,0
l1
6,0
7,0
8,0
10,0
12,0
14,0
18,0
22,0
l2 l
12 60
20 60
20 70
26 80
32 90
36 100
46 120
52 120
Nennwertbereich / Diameter range (mm)
>3-6
0
-48
0
-8
> 6 - 10
0
-58
0
-9
> 10 - 18
0
-70
0
-11
> 18 - 30
0
-84
0
-13
Seite
Page
98–105
dA
d
= Hauptanwendung / Main application
= Nebenanwendung / Suitable
Alle Angaben in mm / Dimensions in mm
